หมายเลขรุ่น: GSKJ-GBS
| ดาวน์โหลด | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Specification | |||||||
| Inside Diameter |
Tolerance on Diameter |
Wall thickness -1.5KV |
Wall thickness -2.5KV |
Wall thickness -4.5KV |
Wall thickness -7.5KV |
||
| 0.5 to 3.5 | +0.3-0 | 0.32±0.12 | 0.36±0.15 | 0.45±0.15 | 0.50±0.15 | ||
| 4.0 to 9.0 | 0.45±0.15 | 0.46±0.15 | 0.48±0.15 | 0.53±0.15 | |||
| 10 to 12 | +0.5-0 | 0.50±0.20 | 0.52±0.20 | 0.58±0.20 | 0.58±0.20 | ||
| 14 to 16 | 0.68±0.20 | ||||||
| 18 to 30 | +0.8-0 | 0.70±0.25 | 0.72±0.25 | 0.78±0.25 | 1.20±0.30 | ||
| Characteristics: | |||||||
| characteristics: | Results | ||||||
| After heating | No cracking or detachment of the coating after 8 hours at 220℃. |
||||||
| Low temperature | No cracking or detachment of the coating after 60 minutes at-60℃. |
||||||
| Flame propagation | Max 10 sec(According to ULVW-1). | ||||||
